Zoom LiveTrak L6max Digital Mixer + Recorder

Big Mixer Energy

The LiveTrak L6max is packed with all the features youd expect from a full-size mixer, plus a multi-track recorder. Its compact, battery powered, and ready to be the centerpiece of your live show, rehearsal, or podcast.

Small Enough for a Duo, Big Enough for a Band

Whether you are a full-band, an acoustic duo or a solo performer, the L6max is ready. With 4 combo inputs (including 2 with Hi-Z) and 8 line inputs, its 12 channels offer the flexibility you need for any session.

Custom Monitoring Options

Two headphone outputs with one customizable Sub-Out mix let you monitor exactly what you need, wherever you are on stage.

High-Output Ready

Channels 58 include a -20 dB PAD switch so you can handle loud sources such as vintage synths and Eurorack modules. No attenuator required.

OLED Display

The high-contrast OLED display helps you create projects and adjust settings with ease.

Powerful Multi-Tracking

14 Tracks of Recording

Capture up to 12 individual tracks plus a stereo mix directly to SD cards up to 2TB. Projects can be saved and recalled for mixing anytime.

Unlimited Overdubbing

You can mix and bounce tracks to the dedicated bounce track freeing up additional channels to keep adding layers. If the bounce doesnt hit the mark, undo it and try again. Even after a bounce Individual files are saved to the SD card for future mixing.

AI Noise Reduction

Turn on AI Noise Reduction and let the L6max intelligently remove hum, hiss, and background noise – while preserving every detail of your voice and instruments.

Lets Get Loud

For huge drums and loud guitar solos, the L6max records clip-free audio in 32-bit float. Channels 1-4 have dual-AD converters, keeping mic signals pristine across extreme dynamics.

3-Band EQ for Every Channel

Dial in the perfect tone with LOW, HIGH, and MID EQ on each channel

Onboard Effects

Build the perfect mix with onboard effects including Reverb, Delay, and Echo. Use the TAP key to set delay times.

Advanced Compressor

The master track compressor adds punch and saturation to your mix. With 32-bit float the audio will never clip, even at high volumes.

Easily Record with your Smartphone or Computer

The L6Max can be used as a 32-bit float 12-in / 4-out USB audio interface for your computer, iOS, or Android device while recording simultaneously to the microSD card. Its also a control surface for your favorite DAW.

Pro-Level Mixer Functions

A. MIDI I/O and USB MIDI
Connect external synths and grooveboxes or integrate with MIDI apps on your computer and mobile devices.

B. Flexible Routing with AUX Sends
Two AUX Sends with pre/post-fader options for FX loops and monitor feeds.

C. Sound Pads with MIDI Sync
Trigger jingles, sound effects, or samples on demand. Sound Pads can even sync to a MIDI clock for live electronic performances.

D. Scene Memory
Store up to four mixes and recall them anytime with a single button.

Customize with the L6 Editor App

The free L6 Editor app for Mac and Windows lets you customize pads, effects, and MIDI assignments with ease.

Stay Powered, Stay Mobile

Power the L6max via AA batteries, USB bus power, or a mobile battery pack.

Euro Rack Integration

The L6max is mountable to a standard Eurorack case using the optional ERL-6 rack ears and power supply.

Dimensions

284 mm (W) 114 mm (D) 46.5 mm (H)

Weight (main unit only)

673 g

Weight (including batteries)

767 g
